Specifications
Product Specifications
| Product Range | Neon Flex |
| LED Strip Type | Colour Tuneable White |
| LED Pitch | 8.33 mm |
| LED’s per metre | 112 |
| LED Cut Point | 125 mm |
| Dimensions | 12 mm x 20 mm x 5.05 m (Reel length) |
| Colour Temperature | 6500 K |
| Lifetime | up to 35000 hours |
| Mounting Method | See product accessories |
Product Performance (Based on 1000m)
| Voltage | 24 V |
| Power Consumption | 12 W |
| Power Split – Warm White | 6 W |
| Power Split – Cool White | 6 W |
| Lumen Output | 340 lm |
| Lumen Split – Warm White (2200K) | 160 lm |
| Lumen Split – Cool White (6500K) | 180 lm |
| Lumen Efficiency | 28 lm / W |
| Maximum Continous Run (Powered from one end) | 5 m |
| IP Rating | IP 65 (IP 67 available) |
| CRI (Ra) | 90+ |
| Colour Binning Step | 3 SCDM (2 SCDM available) |
| Operating Temperature | -20°C ~ +50°C |
